Blink Pro - 9W; 5in; LED Fixture; CCT Selectable; Round Shape; White Finish; 120V : 62/1700

No Image
Available

Image may not reflect selected features

Blink Pro - 9W; 5in; LED Fixture; CCT Selectable; Round Shape; White Finish; 120V (62/1700) by Nuvo

Blink Pro - 9W; 5in; LED Fixture; CCT Selectable; Round Shape; White Finish; 120V

Product Specification

Item #

62/1700

Dimensions

Height: 0.67"

Width: 5.00"

Additional product details

Vendor Item #

62/1700

Category

Close-to-Ceiling

Sub Category

Edge Lit

Style

Utility

Additional Info

UGR - 28.89; SDCM - 464; Hi pot - DC-1550V; Edge-lit - Yes

Avg Rated Hours

50000

Bulb Shape1

Integrated LED

Bulb Type1

LED

Color Temperature

Warm White to Natural Light

Diameter

Dimmable

Yes-Dimmable

Each Height

5.2

Each Length

5.2

Each Width

1.81

Lumens

700L-780L

Tariff Code

9405.11.8020

Warranty

5 Year Limited - Fixtures

Amps

0.075A

ANSI Base

Integrated

BAA Compliant

Beam Angle

100

CA Prop-65

Lead

CCT Selectable

Yes

CEC

California T24 2016 - 2022 JA8 Listed

CEC Terse

Lawful for sale in California

CEC Web Text

California T24 Listed

Closet Rated

Yes

Country Of Origin

Thailand

CRI

Dimmable Down To

100 to 10 percent

Dimmable Function

120V only

Each Cube

0.0283

Each Quantity

Efficacy

77.78/82.22/86.67 LPW

ES Category

Downlight Surface Mount

ES Unique ID

ESID-3553075;2402966

FCC Compliant

Yes

Feature 1

Integrated LED featuring 9 watts, CCT Selectable from warm to natural light, 90 CRI

Feature 10

Easy installation with included instructions

Feature 2

Fixture is dimmable, selectable from 700 to 780 lumens, with a beam spread of 100

Feature 3

5 inch Diameter x 0.67 inch Height

Feature 4

White Finish with Acrylic Panel

Feature 5

Closet rated with zero clearance from storage material

Feature 6

Ideal for corridors, closets, kitchens, bathrooms, bedrooms, including outdoors as they are wet location rated with closed ceiling applications

Feature 7

Rated for 50,000 hours

Feature 8

5 year warranty

Feature 9

Visit Satco.com for optional accessories: 5 inch round extension collar; White - 25-1700, Black - 25-1701, Bronze - 25-1702

Finish Family

White

Fixture shape

Round

Flicker Free

Incandescent Equivalent

60W

Indoor Outdoor

Indoor

Installation Notes

Surface mount; Compatible with 3in. & 4in. J-box and pancake J-box with additional accessory

JA8 Compliant

Yes

Lens Material

Poly methyl methacrylate (PMMA)

Long Description

From designer aesthetics to state-of-the-art technology, BLINK's ENERGY STAR certified fixtures embody this concept entirely. The sleek, low-profile style features die-cast construction, and is CCT selectable, with five preset options from warm to natu

Material

Die-Cast Aluminum

Mounting Procedure

Ceiling

NEC Compliance

Clothes Closet Certified - Reg: 410.16 (A)(3) and 410.16 (C)(5)

Operating Frequency

60Hz

Operating Temp

-20C (-4F) to +40C (+104F)

Pack Type

Box

Power Factor

0.9

Quantity In Pack

Replaceable Light Source

RoHS Compliant

Yes

Romance Copy

Safety Listing

cETLus - Listed

SDS class

LED_Fixture

Short Description

BLINK 9W LED 5" RND WHITE

Sloped Ceiling Compatible

Yes

Specification Notes

Overall height of fixture and driver: 1.59"

Temperature (CCT)

2700K/3000K/3500K/4000K/5000K

Title 20 Compliant

Title 24 Compliant

Yes

Total Harmonic Distortion

<20%

Wattage Selectable

Weight Lb.

0.59

Manufactured By

Nuvo

Finish
